50. How to Improve Fleet Safety

    Preventative Measures Using AI, Cameras, and Dashcams by Richmor Systems. Fleet safety isn't  just about keeping vehicles on the road, it’s essential to protecting lives, preserving business investments, and maintaining a strong reputation.

    BK6MZH Main Features:
    1. Mini size, multi option 1CH-3CH*1080P, h,265
    2. Impressed video quality, easy installation (I can share you the videos)
    3. Nice competitive price: $5X~$8X
    4. AI functions optional: DSM & ADAS
    5. High capacity storage upto 512GB
    6. Wide-voltage, Low consumption DC 6-36V, suitable for all type Vehicle from personal car to high-weight truc
    7. Over value: support RS232, Canbus, OBD, SOS
    8. Built-in GPS, 3G/4G, WIFI, G-sensor, Mic and Speaker, support intercom.

50. H.265/H.H.265/H.264 hardware compression, powerful AI processor, with neuron logical reasoning engine, support for deep learning algorithms.
50. It can support up to 3 video inputs; Integrated front and rear dual-channel 1080P cameras, integrated infrared lights in the car can achieve all-weather monitoring. It can be expanded with 1 camera input, which is suitable for more scene monitoring.
50. Optional DMS camera extension;
50. DMS camera driving behavior analysis - can be connected to DMS camera, alarm prompts for the driver's dangerous driving behavior and upload to the monitoring center, including: fatigue (eyes closed, yawning), distraction, smoking, phone calling, not wearing a seat belt, not wearing a safety helmet, etc.
50. Driver face recognition function - on the basis of management, face recognition attendance can also prevent drivers from violating the rules of substitute shifts, non-compliant driver operations, and standardize driver and operation management.
50. 4G full Netcom, WIFI integration, support operation software monitoring, fast installation and maintenance.
50. Beidou/GPS positioning, support the ministry standard JT/T808, JT/T1076, JT/T905, Jibiao, Subiao and other multi-platform reporting and transmission.

Main features 1. H.265/H.264 compression mode, powerful AI processor, neuron logic reasoningengine, supportdeep learning algorithm. 2. Max support 3CH 1080P video input; Built in dual lenses 1080P cameras for front andcabinview, andinfrared cabin camera supports monitoring for 24 hours even in dark night. Besides, anoptional external camera are flexible to connect. 3. Optional DMS algorithm integration; DMS driving behavior analysis – Detects the driver's dangerous behaviors suchas fatigue(closed eyes, yawning), distraction, smoking, calling, etc. Alarms will be sent toreminddriversand are uploaded into Vehicle management software. 4. Driver's face ID – check attendance driver, avoid non-compliant driver operations, etc5. Beidou /GPS positioning, support real time tracking

 Portable modular 2 channel mini 3g AHD 1080P MDVR

H.265 hard compression mode, maximum support for full real-time 8-channel 1080P; 5-channel audio input (including 1-channel MIC intercom input)
Integrate ADAS forward advanced driving assistance system+DSM dangerous driving behavior warning technology;
Built-in thermal printer, integrated pickup, integrated TTS function
Front window display: 132 * 64 dot matrix screen
Built-in 3.7V/600mAh backup battery. Support GPS upload after vehicle power failure
It supports 2 SD cards for storage, with a maximum of 256GB per card; Two high-speed USB2.0 interfaces;
Support 4G network; Built-in Beidou GPS dual-mode and G-sensor gyroscope.
Support 10-way alarm input (2-way analog quantity+8-way IO alarm input); 2-way switch value alarm output, supporting linkage audible and visual alarm, fuel cut-off and power failure. Support 2-way CAN interface, 2-way RS232, 1-way RS485
Support card reader, voice intercom and mobile phone call. Expandable fuel sensor and other peripheral devices
Power supply: support 8V-36V. External dimension: 180mm * 53mm * 170mm

1.H.265/H.H.265/H.264 hardware compression, powerful AI processor, with neuron logical reasoning engine, support for deep learning algorithms.

2.It can support up to 3 video inputs; Integrated front and rear dual-channel 1080P cameras, integrated infrared lights in the car can achieve all-weather monitoring. It can be expanded with 1 camera input, which is suitable for more scene monitoring.

3.Optional DMS camera extension;

4.DMS camera driving behavior analysis - can be connected to DMS camera, alarm prompts for the driver's dangerous driving behavior and upload to the monitoring center, including: fatigue (eyes closed, yawning), distraction, smoking, phone calling, not wearing a seat belt, not wearing a safety helmet, etc.

5.Driver face recognition function - on the basis of management, face recognition attendance can also prevent drivers from violating the rules of substitute shifts, non-compliant driver operations, and standardize driver and operation management.

6.4G full Netcom, WIFI integration, support operation software monitoring, fast installation and maintenance.

7.Beidou/GPS positioning, support the ministry standard JT/T808, JT/T1076, JT/T905, Jibiao, Subiao and other multi-platform reporting and transmission.

360system is integrated in our AI MDVR, so just connect to 4 cameras(front, rear and 2 sides cameras), a whole panoramic view will be formed.

Besides, other functions are optional such as ADAS(Lane departure warning, headway monitoring warning, forward collision warning), DMS(Fatigue, distraction, smoking, calling), BSD(blind spot detection)...

• H.265/H.264 hardware compression, powerful AI processor, with neuronal logic reasoning engine, support for deep learning algorithm.
• Integrated ADAS camera, can expand 1 or 2 AI camera input. Support DSM and environmental monitoring.
• ADAS (Advanced Driver Assistance Systems)——Integrated with ADAS camera, supports lane departure detection and warning, forward collision detection and warning, headway monitoring warning, pedestrian collision warning
• DMS (Driver Monitoring System)——warnings will be given to remind drivers and uploaded into the VMS once DMS camera detects dangerous driving behaviors such as: fatigue (closing eyes, yawning), distraction, smoking, calling etc
• Driver face recognition function——check attendance driver, avoid Non-compliant driver operations, etc.
• Beidou /GPS positioning, support tracking.

 Stable high-quality processor solution, H.264/H.265 compression, support mixed video input.

◆ Real time AHD or IPC video recording, 1080p / 720p / D1 / HD1 / CIF optional, adjustable frame rate and image quality.

◆ 4CH/8CH AHD, max full 1080P. Or 4CH AHD + 4CH IPC.

◆ 2CH video output. Support 1CH BNC, optional 1CH VGA.

◆ 6CH IO alarm input (door opening and closing, lighting, steering, braking, reversing can be configured ), 2CH IO alarm output.

◆ Support RS232 + RS485 for sensors, supports RJ45 for local internet for IPC camera connection, support USB port for parameter input and output, upgrade.

Industrial design:

◆ Professional MDVR power design, 8-36v DC voltage input; Support Power mode/ACC mode/Sleep mode/Timing mode. Support delay off time, max 24 hours. Protection for overload / undervoltage / short circuit, which is suitable for various vehicles.

◆ Provide DC12V and DC5V power output, which can provide constant voltage power for cameras, small screens, sensors and so on.

◆ Support ACC delay off function, device can work after ignition is off (Max 24 hours). Support sleep mode, built-in 3.7v/600mAh (Max1200mAh) backup battery, support GPS upload after vehicle outage.

◆ Protection of car accident outage: Super capacity built-in, which can make the machine work normally for 5-8s when power supply is totally off，so as to ensure the integrity of video and facilitate accident investigation.

◆ SD card + Hard disk recording (max 2TB + 1*128GB), Physical and digital level hard disk protection technology can avoid damage by vibration and dust.

◆ The unique pre-allocated MDVR system can solve file fragments caused by repeated erasure, ensure the stability and integrity of data.

◆ Watchdag abnormal recroding reboot function, better protects machine ans video.

◆ Auto-video recording, manual video recording, alarm video recording and other video recording methods to meet different needs.

◆ Overlay function can indicate vehicle driving status, license plate, speed ect. on the the video.

Network function:

◆ Support GPS / BD, GLONASS optional. RTK high-accuracy positioning module optional. Support Geo-defence.

◆ Support 3-axis G-sensor. Support alarms, even snaps and videos uploading to server for tilt and collision.

◆ Support 4G, WIFI (optional). WIFI support AP mode and Station mode.

◆ Support remote checking parameter and config using platform, OTA.

◆ Remote support for A/V live monitoring, two-way voice intercom, remote PTZ control, Emergency alarm, overspeed alarm, cross-border and route deviation alarm.

◆ Support remote monitoring via phone and mobile phone call function.

AI function:

◆Integrated ADAS (efficient alerts: lane departure detection, front vehicle collision detection, etc.).

◆Integrated DSM, driver facial recognition (efficient driver’s behavior alerts: Fatigue, Distraction, Smoking, making call, etc.)

◆Integrated BSD blind Spot detection algorithm (efficiency alerts for side people, vehicles, bicycles..)

◆ Customization functions which are based on customer requirements!
