• H.265/H.264 hardware compression, powerful AI processor, with neuronal logic reasoning engine, support for deep learning algorithm.
• Integrated ADAS camera, can expand 1 or 2 AI camera input. Support DSM and environmental monitoring.
• ADAS (Advanced Driver Assistance Systems)——Integrated with ADAS camera, supports lane departure detection and warning, forward collision detection and warning, headway monitoring warning, pedestrian collision warning
• DMS (Driver Monitoring System)——warnings will be given to remind drivers and uploaded into the VMS once DMS camera detects dangerous driving behaviors such as: fatigue (closing eyes, yawning), distraction, smoking, calling etc
• Driver face recognition function——check attendance driver, avoid Non-compliant driver operations, etc.
• Beidou /GPS positioning, support tracking.

 Stable high - quality processor  solution, H.264/H.265 compression, support mixed video input .  (H.265+ optional)

◆ Real time A HD or IPC  video recording, 1080p  / 720p / D1 / HD1 / CIF optional, adjustable frame rate and image quality .

◆  4CH/8CH AHD, max full 1080P. Or 4CH AHD + 4CH IPC .

◆ 2CH video output . Support 1CH BNC, optional  1CH VGA .

◆ 6 CH IO alarm input  (door opening and closing, lighting, steering, braking, reversing can be configured), 2CH IO alarm output .

◆ Support  RS232 + RS485 for sensors , supports  RJ45 for local internet for IPC camera connection, support USB  port for parameter input and output, upgrade.

Industrial design:

◆ Professional MDVR power design, 8-36v DC voltage input ; Support Power mode/ACC mode/Sleep mode/Timing mode . Support delay off time , max 24 hours. Protection for overload / undervoltage / short circuit , which is suitable for various vehicles .

◆ Provide DC12V and DC5V power output , which can provide constant voltage power for cameras, small screens , sensors and so on.

◆ Support ACC delay off function, device can work after ignition is off ( Max 24 hours ) . Support sleep mode , b uilt-in 3.7v/600mAh (Max1200mAh) backup battery ,  support GPS upload after vehicle outage.

◆ Protection of car accident outage : Super capacity built-in, which can make the machine work normally for 5-8s when power supply is totally off , so as to ensure the integrity of video and facilitate accident investigation.

◆ SD card + Hard disk recording  (max 2TB + 1*128GB), Physical and digital level hard disk protection technology can avoid damage by vibration and dust.

◆ The unique pre-allocated MDVR system  can solve file fragments caused by repeated erasure, ensure the stability and integrity of data .

◆  Watchdag abnormal recording reboot function , better protects machine ans video.

◆ A uto-video recording, manual video recording, alarm video recording and other video recording methods to meet different needs.

◆ Overlay function  can indicate  vehicle driving status, license plate, speed  ect . on the the video .

Network function:

◆ Support GPS / BD , GLONASS, etc optional. Support Geo-defence.

◆ Support G-sensor . Support alarms, even snaps and videos uploading to server for tilt and collision.

◆ Support 4G, 5G, WIFI (optional) . WIFI support AP mode and Station mode.

◆ Support remote checking parameter and config using platform, OTA .

◆ Remote support for A/V live monitoring , two-way voice intercom , remote PTZ control , Emergency alarm , overspeed alarm , cross-border and route deviation alarm .

◆  Support remote monitoring via phone and mobile phone call function .

AI function:

◆ Integrated ADAS  ( effective  alerts: lane departure detection, front vehicle collision detection, etc. ).

◆ Integrated DSM ,  driver facial recognition  (efficien t  driver's behavior alerts: Fatigue, Distraction, Smoking,making call, etc.)

◆ Integrated BSD  blind Spot detection algorithm ( efficiency alerts for side people, vehicles, bicycles..)

◆  Customization functions which are based on customer requirements !

Main futures:

1.1-3CH  1080P high definition video recording
2.WIFI, 4G, GPS, G-Sensor
3.SD Card Storage MAX 512G
4.AI: DSM, Safety belt, Driver face ID, BSD
5.Overspeed, Driver face Control
6. Bluetooth wireless Speed sensor
7. Waterproof, anti-violent IP69K,

8. Wide-power design 8V-110V

Richmor Al People Counting MDVR, utilizes the most advanced Al technology (no longer Toftechnology), to provide the best performance of passenger counting solution, with the 99%highest level of accuracy, and can work in complicated ambient light environment, in bus doorscenarios. Easy and costly solution with one camera for two way people counting.
