Richmor True AI ADAS DSM BSD Driver Fatigue Detection Pedestrian Detection Truck MDVR

• OS: Embedded Linux
• CPU Speed: 1.2GHZ
• NOR FLASH CAPACITY: 32MB NOR+128M NAND
• RAM CAPACITY: 1G
• Video Input: 8 channel AHD HD analog input, aviation connection, 1.0Vp-p, 75Ω
• Video Output: 2channel composite video output，1.0Vp-p，5 Ω, VGA input (optional), 1 channel / 2 channel / 5/4 picture segmentation / 9/6 picture segmentation
• Preview: Support single CH /2 CH /4 CH /5 CH /6 CH /8 CH /9 CH splicing preview, support manual/event trigger full-screen display function
• Resolution: 1080P/720P/D1/HD1/CIF,can be optional, max support 8channel 1080P
• Image Quality: 0-7 levels, 0 is the highest level, 7 is the lowest level.
• Recording Mode: Default automatic recording, support ACC Power on、Manual recording、 alarm recording and etc
• Analog output: 1ch preposition analog output; 1ch postposition analog output(aviation)
• Input channel: 8CH
• AGC Control: Automatic
• Sampling frequency: 8/16K
• Sampling accuracy: 16
• Audio output:
• Interface Type: 4-core 12M-4B aviation connection/4-core 3.5mm headphone connection
• Output channel: 3channel
• Mute: support
• Position :
• GPS/BD: Supports dual mode positioning
• Precision: ≤10m(95%)
• starting time: warm reboot≤5s, cold reboot≤45s
• repeat positioning : 1s
• 3G/4G wireless:
• Module type: TDD-LTE, FDD-LTESupport build-in 4G wireless transmission,TDD-LTE, FDD-LTE
• protocol: UDP,TCP/IP
• voice service: HR/FR/EFR和AMR
• message service: SMS
• Alarm input: 6CH IO alarm input, 2CH AD input, 2CH pulse speed input; with alarm linkage function
• Alarm output: 2CH switch output, linkage sound and light alarm, oil cut-off, etc.
• Communication Interface:
• 2CH RS232, can be external station announcement, oil sensor, LED advertising screen, etc.
• 1CH 485 interface, can support PTZ
• 1CH CAN interface
