Richmor 3G H.264 SD Card Mobile DVR for Bus / Taxi TrackinRichmor 3G H.264 SD Card Mobile DVR for Bus / Taxi Trackin

Richmor 3G H.264 SD Card Mobile DVR for Bus / Taxi Trackin

  • Factory Direct sale, competitive prices
  • 3G GPS for optional
  • Channel 1-4, 1-4 cameras can be connected
  • High Definition D1, H.264
  • CE RoHS FCC Approval
  • Richmor products' advantages:
  • 1. Protection against power failure.
  • 2. A wide voltage (10-36V).
  • Third OTA support functions. (Software Upgrating DVR automatically better after-sales service for you, we can only achieve IT in China for now.)
  • 4th SMS can get DVR situation feedback from DVR. (We can only achieve IT in China for now.)
  • 5th level industrial design. (More professional and better quality).
  • 6th Modular construction. (To avoid mistake module, while the effect on the entire product).
  • 7th Encryption video format. (To prevent loss of data)
  • Eighth current and voltage over the protection.
  • 9th Wide operating temperature. (-25 ℃ - + 75 ℃).
  • 10th data redundancy technology. (To prevent loss of data)
  • 11th Very good protection against vibration.



Richmor 128 gigabytes 128 gigabytes + SD card MOBILE DVR with 3G / 4G / WIFI GPS G-Sensor



Model number.                         FUNCTION
RCM-MDR210XXXI
slot Basic Recording G-Sensor Single SD Card
RCM-MDR210WGXX 3G GPS G-Sensor   SD card slot Single
RCM-MDR210FGXX 4G GPS G-Sensor  SD card slot Single
RCM-MDR210WGWX 3G GPS WIFI G-Sensor SD card slot Single
RCM-MDR210WGDX 3G GPS WIFI G-Sensor Dual SD Card Slots
RCM-MDR210FGWX 4G GPS WIFI G-Sensor SD card slot Single
RCM-MDR210FGDX 4G GPS WIFI G-Sensor Dual SD Card Slots







benefits








Motto:



RCM-MDR210 parameter Sheet

Item

Parameter

OS

Linux

Language

Chinese / English / tailor

video compression

H.264

OSD

Overlapping information such as date and time of vehicle ID

GUI

Graphical user interface

installation of system parameters with remote control.

Video Record System

video input

4CH 720P AHD entry, aviation connector, 1.0Vp-p, 75Ω

video output

1 CVBS, 1.0Vp-p, 75Ω, aviation support 1CH Full Screen, 4CH Screen

Preview

Support one channel and 4 channels preview., Support manual / alarm trigger full-screen preview

Distinction

720P / D1 / HD1 / CIF MAX: 720P 4 channels and 4 channels of D1

video quality

1-4 levels, one is at the highest level.

video Standard

PAL: 100F / s, CCIR625 line, 50field;

NTSC: 120f / s, CCIR525 line, 60field;

CIF: 256kbps ~ 1.5Mbps, 8 levels of video quality, optional;

HD1: 600kbps ~ 2.5Mbps, 8 levels of video quality, optional;

D1: 800kbps ~ 3 megabytes, 8 levels of video quality, optional;

720P: 4Mbps-6 Mbps, multi-level video quality optional

recording mode

The default setting is automatic recording after switching. The timer recording, alarm triggered recording, and manual recording are supported.

audio

audio input

4CH, Air Plug

audio output

1CH, Air Plug

Compression

G.726 compression, 8KB / s speed

alarm Input

3 CH alarm input, alarm types of support custody

alarm output

1CH Alarm Output

Position

Built-in support for GPS / BD Module

G-Sensor

Support G-Sensor

Storage space

SD

Dual SD card, each loop recording SD card up to 128 gigabytes

Upgrading

Support SD card update

file format

.H264

file system

Special FAT32

video playback

video Search

Search by Time Record / Record Type etc

playback

Maximum support 4CH Replay / Stop / Fast / Slow at the same time

Support for forward and reverse play speeds: x2, x4, x8, x16.

Voltage & Urine

power management

Wide Voltage.Support Timed / Delay off

input voltage

DC: + 10V ~ + 36V

voltage Output

+ 12V ~ 2.5A, + 5V ~ 2.5A

Power consumption

Normal Working & lt; 5W

Working environment

Temperature

-20 ℃ to + 70 ℃

Humidity

20% to 80%

Safety

Password

User / Administrator Level 2 different password

other

Size

112 (W) X36 (H) x138 (D) mm

Net weight

360 g







software player interface

















Application

Widely used in cars and buses, taxis, school bus, truck, dangerous vehicles, passenger cars and boats, etc.





 CIMG5257_







buying Guides



Packaging



1 unit with all standard accessories like AV cables / IO cable / power cable / etc Key



  Neutral cardboard boxes or paper boxes Color logo printed Richmor, Also welcome customized package.






packing box





shipping





Strong worked with DHL / UPS Etc fast and safety delivery.



A. 2-5 days after payment clearing for sample order.

b. 5-10 days after payment clearing depends on order quantity for bulk orders.
